Product Description

Shenzhen Jiayunkang Technology Co., Ltd. presents its next-generation Electrical Waterproof Push-in Multi-Pin Connector, a solution designed to revolutionize connection efficiency without compromising on environmental protection. This connector series is engineered for modern industrial applications where speed of assembly, space savings, and absolute reliability are critical. It integrates a user-friendly push-in locking mechanism with a robust, sealed design, making it the ideal choice for panel builders, machine manufacturers, and system integrators across various sectors.

The connector features a multi-pin configuration that allows for the simultaneous transmission of power, signals, and data within a single, compact housing. Built to meet stringent IP67/IP68 standards, it guarantees complete protection against dust, moisture, and high-pressure water jets, ensuring uninterrupted performance in indoor, outdoor, and harsh industrial settings. This product exemplifies our commitment to innovation in connector technology, providing a plug-and-play solution that reduces installation time while maximizing system uptime.

Product Features

Push-in Locking Mechanism: Enables quick and tool-less mating and unmating, significantly accelerating installation and servicing processes. An audible click confirms a secure connection.

High-Ingress Protection (IP67/IP68): Equipped with integrated silicone seals, precision O-rings, and a threaded coupling system to form a complete barrier against water, dust, and humidity.

Multi-Pin Configuration: Available in 3 to 24-pin variants, allowing for consolidated power and signal connections, which reduces clutter and simplifies cable management.

Vibration and Shock Resistant: The positive lock of the push-in mechanism, combined with a robust housing, ensures a stable connection even in high-vibration environments like automotive or heavy machinery.

Corrosion-Resistant Materials: Housing is made from high-quality, UV-resistant PA66 or PBT material, with gold-plated or tinned copper contacts to prevent corrosion and ensure long-term electrical stability.

Broad Operating Temperature Range: Engineered to perform reliably in a wide temperature span, from -40°C to +105°C, suitable for extreme climatic conditions.

Product Advantages

Drastic Reduction in Installation Time: The push-in technology eliminates the need for tools during connection, cutting wiring time by up to 60% compared to traditional screw-type connectors, leading to lower labor costs.

Enhanced System Reliability: The superior sealing performance prevents costly downtime and equipment failure caused by environmental factors, a critical advantage for outdoor LED applications, display screens, and automation systems.

Space-Efficient Design: By combining multiple circuits into a single, compact connector, it saves valuable space in control cabinets, machinery, and lighting fixtures, enabling more compact and streamlined designs.

Minimal Maintenance Requirements: The high reliability and durability of the connector translate into minimal maintenance needs over its lifecycle, reducing the total cost of ownership.

Error-Proof Assembly: The polarized design prevents incorrect mating, safeguarding sensitive electronic components in computers, communications gear, and medical equipment from damage due to miswiring.

Application Fields

This versatile connector is designed to meet the rigorous demands of numerous industries where a waterproof, quick-connect solution is paramount.

Industrial Automation: For connecting PLCs, I/O modules, sensors, and actuators on robotic cells and assembly lines.

Outdoor LED Lighting & Signage: Ideal for LED street lights, architectural lighting, stadium lights, and large outdoor display screens, where waterproofing is essential.

Machinery & Equipment: Provides robust interconnections for control systems in packaging, food processing, and textile machinery.

Renewable Energy: Used in connections for solar inverter systems and wind turbine control boxes.

Transportation & Automotive: Suitable for internal wiring in commercial vehicles, buses, and for connecting auxiliary equipment.

Marine Electronics: For navigation equipment, bilge pumps, and other onboard systems exposed to moisture and salt spray.

Frequently Asked Questions (FAQ)

Q1: How does the push-in locking mechanism work, and is it secure?
A: The mechanism uses a spring-loaded latch. When the plug is inserted into the receptacle, the latch engages with a positive lock, producing an audible click. This design is highly secure against vibration and accidental disconnection.

Q2: Can these connectors be used with solid core wires?
A: They are primarily designed for use with stranded wires for optimal grip and contact. Using solid core wires is not recommended as it may not provide a reliable, gas-tight connection in the push-in contact spring.

Q3: What is the difference between IP67 and IP68 ratings for this product?
A: An IP67 rating certifies protection against temporary immersion in water (up to 1 meter for 30 minutes). An IP68 rating offers a higher level of protection, suitable for continuous immersion in water under conditions specified by the manufacturer (e.g., greater depth and duration).

Q4: Are the connector contacts pre-loaded, and what termination method is used?
A: Yes, the contacts are typically pre-assembled in the housing. Field termination is done by inserting a properly stripped wire directly into the contact chamber until it clicks into place. A standard release tool is used to disengage the wire when needed.
