Product Description

The Three-way Waterproof Connector represents a significant advancement in multi-port connection technology, specifically engineered to address complex wiring challenges in demanding environments. This innovative connector features a unique trifurcated design that allows simultaneous connection of three separate circuits through a single IP68-rated interface. Manufactured by Shenzhen Jiayunkang Technology, this solution combines superior waterproof performance with exceptional mechanical durability, making it ideal for applications where space optimization and environmental protection are critical. The connector utilizes advanced silicone sealing technology and corrosion-resistant materials to ensure reliable performance in extreme conditions, including prolonged exposure to moisture, chemicals, and temperature variations.

Product parameters

Product Model :T15 type connector

Number of cores :2/3 pin

Shell material: Nylon (PA)

Rated voltage :250V

Rated current :10A

Waterproof rating :IP67/68

Operating temperature :-40℃±105℃

Cable diameter :OD≤ 8.2mm in diameter

Connection method: Nut butt joint

Product Features
Triple Circuit Integration
Innovative three-way design consolidates multiple connections into a single compact unit, reducing installation space by 60% compared to individual connectors. Each circuit maintains independent isolation while sharing a common protective housing.

Enhanced Sealing Technology
Multi-layer sealing system featuring primary silicone O-rings, secondary epoxy encapsulation, and tertiary mechanical sealing provides complete environmental protection. The triple-seal design ensures waterproof integrity even under high-pressure washdown conditions.

Advanced Contact Technology
Silver-plated copper contacts with anti-oxidation treatment ensure optimal conductivity and corrosion resistance. The precision-machined contacts provide consistent mating force and low insertion loss across all three circuits.

Mechanical Durability
Glass-filled polyamide housing with stainless steel locking mechanism offers exceptional impact resistance and mechanical strength. The housing maintains dimensional stability across the entire operating temperature range.

Color-Coded Identification
Integrated color-coding system (red, blue, yellow markers) enables quick circuit identification and prevents miswiring. The intuitive design reduces installation errors by 80% compared to Standard Connectors.

Quick-Connect System
Bayonet-style coupling mechanism with ¼ turn locking provides secure connection with audible engagement confirmation. The tool-free design enables rapid installation and maintenance without special equipment.

Product Advantages
Space Optimization
The compact three-in-one design reduces panel cutouts and installation space requirements, particularly valuable in applications where real estate is limited, such as control cabinets and compact machinery.

Installation Efficiency
Single connector installation replaces three separate connections, reducing wiring time by 70% and minimizing potential failure points. The color-coded system further accelerates installation and maintenance procedures.

Cost Effectiveness
Consolidated connector design reduces overall component costs, inventory requirements, and installation labor expenses. The durable construction minimizes replacement costs and maintenance downtime.

Reliability Enhancement
Superior IP68 protection ensures uninterrupted operation in the most challenging environments. The robust construction withstands vibration, mechanical stress, and environmental contaminants that would compromise standard connectors.

Safety Compliance
Meets international safety standards including UL, CE, and RoHS certifications. The completely enclosed design prevents accidental contact with live parts, enhancing operator safety.

Application Fields
Industrial Automation

• Multi-sensor junction boxes

• Robotic arm connections

• Control panel interconnections

• Motor power and feedback systems

Outdoor Lighting Systems

• Landscape lighting arrays

• Street light controllers

• Architectural lighting networks

• Solar lighting systems

Marine and Offshore

• Navigation equipment

• Deck machinery controls

• Underwater sensor arrays

• Communication systems

Transportation Infrastructure

• Traffic signal systems

• Railway signaling equipment

• Toll collection systems

• Vehicle charging stations

Energy Sector

• Solar panel arrays

• Wind turbine controls

• Battery management systems

• Power distribution units

Agricultural Technology

• Irrigation control systems

• Livestock monitoring equipment

• Automated machinery controls

• Environmental sensors
