Product Description
The Y-Type Wire Harness represents the pinnacle of signal transmission connectivity solutions, engineered for applications requiring reliable multi-branch signal distribution. This innovative harness features a unique Y-shaped design that allows single input signals to be efficiently distributed to multiple output points while maintaining signal integrity and minimizing interference. Designed and manufactured by Shenzhen Jiayunkang Technology, these harnesses are available in multiple sizes and configurations to meet diverse industrial requirements. The Y-Type Wire Harness ensures optimal performance in sensitive signal transmission applications through precision engineering, premium materials, and rigorous quality control, making it an ideal solution for complex electrical systems where signal fidelity is paramount.

Applications:

LED industry, smart lighting, plant lights, LED wall washers, street lights, underground lamp, stage lighting and other fields.

• Industrial automation and control systems

• Test and measurement equipment

• Data acquisition systems

• Telecommunications infrastructure

• Medical diagnostic equipment

• Automotive electronics testing

• Aerospace and defense systems

• Research and laboratory instruments

• Broadcast and audio-visual equipment

• Renewable energy monitoring systems

Features:

1. Simplify the client-side production process;

2. The junction box is directly connected to the PCB inside the lamps instead of extra wire;

3. The external waterproof structure has stronger protection;

4. Easy to operate and maintain.

Product Features

• Multi-Branch Configuration: Y-shaped design enables single-input to multiple-output signal distribution

• Multiple Size Options: Available in various lengths and conductor sizes from 22AWG to 12AWG

• Enhanced Shielding: Triple-layer shielding (foil, braid, and drain wire) for maximum EMI/RFI protection

• Precision Connectors: Gold-plated contacts ensure reliable connections and corrosion resistance

• Flexible Design: High-strand count conductors provide excellent flexibility and fatigue resistance

• Color-Coded Wires: Easy identification and installation with standardized color coding

• Temperature Resistance: -40°C to +105°C operating range suitable for harsh environments

• Customizable Options: Available with various connector types and pin configurations

Cores Layout:

Parameters:

Frequently Asked Questions (FAQ)

Q1: What is the maximum number of output branches available?
A: Standard configurations include 1-to-2 and 1-to-3 branches, with custom configurations available for up to 1-to-6 branches depending on application requirements.

Q2: Can the harness be customized with different connector types?
A: Yes, we offer customization with various connector types including D-Sub, circular connectors, RJ45, and terminal blocks to meet specific application needs.

Q3: How does the shielding performance compare to individual cables?
A: Our Y-Type Harness provides superior shielding through integrated braided and foil shielding that offers better coverage and grounding compared to individually shielded cables.

Q4: What is the minimum bending radius for installation?
A: The minimum bending radius is 10 times the cable diameter to ensure optimal signal performance and prevent damage to conductors and shielding.

Q5: Are these harnesses suitable for outdoor use?
A: With appropriate connector selection (IP67 rated), the harness can be used in outdoor environments. The cable insulation is UV-resistant and suitable for temperature extremes.

Q6: What quality certifications does the product have?
A: Our harnesses meet UL, CE, and RoHS standards, with specific certifications available based on customer requirements and application needs.

Details:
