Product Description

The JYK-M12 Waterproof Connector Wire Push is a premium-grade electrical connectivity solution engineered by Shenzhen Jiayunkang Technology Co., Ltd. Specifically designed for industrial and outdoor applications, this connector series combines the reliability of the universal M12 form factor with the superior efficiency of a push-pull locking mechanism. It is built to ensure a robust, waterproof, and vibration-resistant connection for power, signal, and data transmission in the most demanding conditions.

This connector is constructed with a high-performance engineering plastic housing and features precision-machined, gold-plated contacts to guarantee optimal signal integrity and low contact resistance. The standout feature is its intuitive push-pull coupling system, which allows for rapid mating and unmating without the need for threading tools, significantly reducing installation and maintenance time. With an IP67 protection rating, it is perfectly sealed against dust and temporary immersion, making it an ideal choice for factory automation, industrial sensors, and outdoor LED lighting systems.

Product Features

Push-Pull Locking Mechanism: Enables quick, tool-free connection and disengagement with an audible click, ensuring a secure and reliable lock even in high-vibration environments.

IP67 Rated Protection: Provides complete defense against dust ingress and can withstand temporary immersion in water up to 1 meter for 30 minutes.

High-Grade Materials: Features a robust PBT housing for excellent chemical, thermal, and impact resistance, along with corrosion-resistant contacts.

Precision Gold-Plated Contacts: Ensures superior conductivity, minimizes signal loss, and provides excellent resistance to oxidation for long-term reliability.

Shielded Version Available: Offers effective protection against Electromagnetic Interference (EMI) for sensitive data and signal transmission.

A-Coded Pin Configuration: Standard A-coding ensures broad compatibility with a vast range of industrial sensors, actuators, and control devices.

Product Advantages

Maximized Operational Efficiency: The push-pull design drastically reduces connection time compared to threaded M12 Connectors, leading to faster machine setup, commissioning, and servicing.

Uncompromised Reliability in Harsh Conditions: The combination of a secure lock, IP67 sealing, and vibration resistance ensures continuous operation, minimizing costly downtime in wet, dusty, or volatile industrial settings.

Reduced Total Cost of Ownership: The durability and long service life of the connector reduce the need for frequent replacements, while the speed of installation lowers labor costs.

Enhanced System Integrity: Superior EMI shielding in specific models protects signal quality in electrically noisy environments, preventing data corruption and ensuring accurate control system performance.

Versatile Application Range: Its robust design and standard M12 footprint make it a future-proof component suitable for upgrading existing equipment and integrating into new systems across multiple industries.

Application Fields

The JYK-M12 Waterproof Connector Wire Push is a versatile solution critical for numerous advanced applications:

Factory Automation & Robotics: Connecting sensors, encoders, PLCs, and actuators on production lines and robotic arms.

Industrial LED Lighting Systems: Providing reliable, waterproof power connections for high-bay lights, outdoor area lighting, and machine vision lighting.

Automation Control Panels: Interlinking components within control cabinets and field devices that require frequent disconnection for maintenance.

Telecommunications & Network Infrastructure: Used in outdoor and industrial networking equipment requiring robust, sealed data connections.

Transportation and Automotive Manufacturing: For machinery and testing equipment that demands rapid, vibration-proof connections.

Renewable Energy Systems: Interconnecting sensors and control units in solar panel arrays and wind turbine systems.

Frequently Asked Questions (FAQ)

Q1: How does the push-pull mechanism work, and is it as secure as a Threaded Connector?
A: The mechanism allows you to simply push the connector into the receptacle to lock it, and pull the sleeve back to disconnect. It is engineered to be highly secure and is specifically designed to resist vibration, making it a reliable and faster alternative to threaded connectors for most applications.

Q2: What is the difference between A-coding and other codings (like B, D) for M12 connectors?
A: A-coded M12 connectors are typically used for sensors, actuators, and DC power. B-coding is for PROFIBUS, and D-coding is for Ethernet (100 Mbit/s). It is crucial to use the correct coding to ensure proper mating and function, as different codings have different keying positions to prevent mismating.

Q3: What is the operating temperature range of the JYK-M12 connector?
A: The standard JYK-M12 connector is designed to perform reliably in a wide temperature range, typically from -25°C to +85°C. Please consult the technical datasheet for specific model variations.

Q4: Can I get these connectors with a customized cable length?
A: Yes. As a specialized manufacturer, we offer customization services, including specific cable lengths, jacket materials (like PUR for oil resistance or PVC for flexibility), and custom coloring to meet your project requirements.
