Product Description

Shenzhen Jiayunkang Technology Co., Ltd. presents a high-performance M12 2-Pin Panel Mount Waterproof Connector, engineered for robust and reliable power connectivity in demanding industrial settings. This connector is specifically designed for permanent installation on equipment panels, enclosures, and machine frames, serving as a steadfast entry or exit point for electrical power. Built to the universal M12 form factor, it ensures seamless integration with a global standard, while its 2-pin configuration is optimized for 2-wire power supply applications.

The connector boasts an IP67-rated construction, guaranteeing complete protection against dust ingress and the effects of temporary immersion in water. This makes it an indispensable component for outdoor use, wash-down areas, and any environment where moisture, coolants, or dust are present. Engineered with precision and durability, our M12 Panel Mount Connector simplifies installation, reduces maintenance costs, and enhances the overall reliability of your electrical systems.

Product Features

Standardized M12 Threading: Features the universal M12x1 metric thread for easy, tool-free mating and unmating with compatible connectors, ensuring broad compatibility.

Robust Metal or PBT Housing: Options include rugged nickel-plated brass for supreme durability or high-strength PBT plastic for excellent chemical and impact resistance.

IP67 Protection Rating: Certified to be dust-tight and capable of withstanding immersion in water up to 1 meter for 30 minutes, ideal for harsh environments.

Secure Locking Mechanism: The reliable thread-locking system ensures a vibration-proof connection, preventing loosening in high-vibration applications like machinery and transportation.

Gold-Plated Brass Contacts: Precision-machined pins with gold plating ensure low contact resistance, superior conductivity, and excellent corrosion resistance for long-term stability.

Wide Temperature Range: Engineered to perform reliably in a broad operating temperature range, typically from -25°C to +85°C, suitable for both extreme cold and hot conditions.

Product Advantages

Maximized System Uptime: The exceptional sealing and vibration resistance drastically reduce connection-related failures, minimizing unplanned downtime in automated production and process control systems.

Streamlined Panel Integration: The panel mount design allows for quick and secure installation into a pre-drilled hole, secured with a locking nut, significantly speeding up equipment assembly and field wiring.

Long-Term Cost Efficiency: Constructed from high-grade materials, this connector offers a significantly longer service life than inferior alternatives, reducing the total cost of ownership and frequency of replacements.

Enhanced Safety: The secure connection and high ingress protection prevent short circuits and electrical failures caused by environmental contaminants, improving overall operational safety.

Design Flexibility: Available in various coding options (typically A-coded for power) and cable outlet directions (straight), providing flexibility for different panel layouts and system designs.

Application Fields

The M12 2-Pin Panel Mount Connector is a versatile solution critical for power delivery in numerous sectors:

Industrial Automation & Robotics: For providing power to sensors, compact actuators, and I/O modules on control panels and machinery.

Outdoor & Industrial LED Lighting: Serving as a waterproof power input for LED luminaires, including street lights, floodlights, and high-bay lighting in warehouses.

Automation Control Systems: Mounted on PLC enclosures and control cabinets as standardized power ports for field devices.

Heavy Machinery & Agricultural Equipment: Withstanding vibration, humidity, and exposure to chemicals in challenging operational environments.

Building Automation: Used in HVAC systems, access control panels, and other building management systems requiring reliable connections.

Frequently Asked Questions (FAQ)

Q1: What is the voltage and current rating of this 2-pin M12 Connector?
A: This 2-pin M12 connector is typically rated for 250V AC/DC and up to 4A, making it suitable for a wide range of low-power devices and sensors. Please confirm the specific ratings in the product datasheet.

Q2: Is this connector truly waterproof?
A: Yes, with an IP67 rating, this connector is completely protected against dust and can withstand temporary immersion in water, making it fully waterproof for outdoor and wash-down applications.

Q3: What panel cutout is required for installation?
A: The standard panel cutout diameter for an M12 connector is 12mm. It is secured from the back with a supplied locking nut.

Q4: Can I use this 2-pin connector for sensor data transmission?
A: While technically possible, the 2-pin version is primarily designed for power. For data transmission, 3, 4, 5, or 8-pin M12 connectors (A-coded for Profinet, Ethernet/IP, etc., or B/D-coded for fieldbus) are the standard and recommended choices to avoid signal interference.
