Product Description

Shenzhen Jiayunkang Technology Co., Ltd. specializes in advanced connectivity solutions built for reliability. Our IP67 Rated Panel Mount Socket Connector is a cornerstone of robust system design, engineered to be seamlessly integrated into equipment panels, enclosures, and casings. This connector serves as a secure, fixed entry or exit point for power and signal transmission, ensuring the internal electronics of your equipment remain completely protected from external contaminants.

Designed to meet the rigorous IP67 standard, this socket connector is guaranteed to be dust-tight and can withstand temporary immersion in water up to 1 meter for 30 minutes. It is the ideal choice for applications where the operational integrity of machinery, lighting, or electronic systems is critical, and exposure to moisture, dust, oils, and cleaning processes is a daily reality. Its panel mount design simplifies installation, providing a clean, professional, and highly resilient interface between the internal and external wiring of any device.

Product Features

IP67 Environmental Protection: Offers complete protection against dust and the effects of immersion in water, ensuring operational integrity in wet and dirty conditions.

Robust Panel Mount Design: Features a nut-and-lock-washer assembly for secure and straightforward mounting on panels of varying thicknesses, from control cabinets to outdoor lighting housings.

High-Grade Materials: The housing is constructed from engineered thermoplastics with excellent resistance to impact, UV radiation, and chemicals, preventing degradation over time.

Secure Screw Lock Mechanism: The coupling mechanism ensures a vibration-proof and tamper-resistant connection, preventing accidental disconnection in high-movement environments.

Precision Gold-Plated Contacts: The internal socket contacts are gold-plated to provide superior conductivity, low resistance, and high corrosion resistance for stable signal and power delivery.

Integrated Sealing Gasket: A high-quality silicone or rubber O-ring is included, which compresses against the panel to form a perfect seal, preventing water and dust ingress from the front.

Product Advantages

Maximizes Equipment Lifespan: By creating a sealed barrier, this connector directly protects sensitive internal components from moisture and corrosive elements, significantly extending the service life of the entire system.

Reduces Maintenance and Downtime: The reliable seal and robust construction minimize the need for maintenance and prevent failures caused by environmental factors, leading to higher overall equipment effectiveness and lower total cost of ownership.

Simplifies System Design and Assembly: The standardized design allows engineers to easily incorporate a proven, reliable connection point into their product designs, streamlining the manufacturing and assembly process.

Ensures Operational Safety: The secure locking and high level of ingress protection prevent short circuits and electrical failures, enhancing the overall safety of the equipment for operators and end-users.

Offers Design Versatility: Available in various orientations (straight or right-angle) and with multiple contact pin configurations to suit different spatial and electrical requirements.

Application Fields

This IP67 Panel Mount Socket Connector is a versatile solution critical for a wide range of industries where environmental sealing is paramount:

Industrial Automation & Control Panels: As a standard power or communication port on PLC housings, motor drives, and sensor array boxes.

Outdoor & Commercial LED Lighting: Integrated into the housing of LED street lights, floodlights, and high-bay fixtures as the primary power inlet.

Food & Beverage and Pharmaceutical Manufacturing: Withstands frequent high-pressure washdowns and exposure to cleaning agents.

Agricultural and Construction Machinery: Provides durable connections on vehicle control units and monitoring equipment exposed to mud, water, and extreme vibration.

Telecommunications and Outdoor Electronic Displays: Used in roadside cabinets, base stations, and large outdoor digital signage.

Marine and Automotive Electronics: Serves as a reliable connection point for navigation equipment, control systems, and specialty vehicle wiring.

Frequently Asked Questions (FAQ)

Q1: What does the IP67 rating mean for this connector?
A: The IP67 rating means the connector is "Ingress Protection" level 6 (completely dust-tight) and level 7 (protected against the effects of temporary immersion in water between 15cm and 1 meter for up to 30 minutes).

Q2: What is the maximum panel thickness this connector can mount to?
A: Our Standard Connectors are designed to accommodate a typical panel thickness range. For specific maximum and minimum dimensions, please refer to the technical datasheet, as it varies by model.

Q3: Can this socket connector be used with any compatible plug?
A: For the IP67 rating to be valid, it must be used with its designated mating plug. Using a non-compliant plug will compromise the seal and void the ingress protection guarantee.

Q4: What tools are required for installation?
A: Installation is typically tool-free for the wire connection side (often using screw-clamp or crimp terminals), and the panel mounting is secured with standard wrenches.
