Product Description

The M12 Line End Wall-Mounted 220V Connector is a robust and highly reliable industrial-grade electrical connection solution engineered for terminating and distributing high-voltage power in demanding environments. As a line-end (plug) connector, it is designed for permanent installation onto control cabinets, machinery frames, or walls, providing a secure and standardized M12 interface for powering industrial devices.

This connector is specifically built to handle 220V AC power, making it an ideal choice for a wide range of automation equipment, industrial sensors, and powerful actuators that require more than the standard 24V DC supply. Constructed from high-quality, industrial-grade materials, it features a durable polyamide housing and superior sealing, ensuring exceptional performance even in the presence of moisture, dust, vibrations, and chemical exposure. By offering a quick-disconnect solution for high-voltage applications, it significantly simplifies maintenance, reduces machine downtime, and enhances overall system safety.

Product Features

High-Voltage Rating: Certified for 220V AC power transmission, suitable for robust industrial equipment.

Secure Mounting: Integrated wall-mount bracket allows for easy and stable fixation on flat surfaces.

M12 Coding: Features standard M12 coding (typically A-coding) for unambiguous, safe power connections.

Superior IP Rating: Boasts an IP67 rating, making it dust-tight and protected against temporary immersion in water.

Robust Construction: Engineered with a high-strength polyamide body and brass nickel-plated contacts for longevity.

Screw Termination: Provides a secure, reliable, and vibration-resistant wire connection.

Temperature Resilience: Operates effectively within a wide temperature range (e.g., -25°C to +85°C).

LED Indicator Option: Available with an integrated LED to provide visual status of power connection.

Product Advantages

Enhanced Operational Safety: This connector's dedicated design for 220V applications, combined with its secure locking mechanism and coding, prevents mismating with low-voltage sensor connectors, a critical safety feature that minimizes the risk of electrical hazards and equipment damage.

Maximized System Uptime: The connector’s IP67 protection ensures reliable operation in harsh conditions, preventing failures caused by coolant, oil, or dust ingress. The wall-mounted design organizes cabling and protects the connection point from strain and accidental dislodgement, leading to fewer interruptions and higher productivity.

Streamlined Installation and Maintenance: The screw-clamp termination and easy-mount bracket drastically reduce installation time compared to hardwiring. Furthermore, the M12 quick-disconnect capability allows for the rapid replacement or servicing of connected devices without the need for tools, slashing maintenance durations and costs.

Application Fields

The M12 Line End Wall-Mounted 220V Connector is versatile and finds critical use across numerous industrial and automation sectors:

Industrial Automation: For connecting PLC systems, motor starters, industrial drives, and control cabinet peripherals.

Robotics: Power supply for robotic arm joints, end-effectors, and control units within robotic workcells.

Packaging Machinery: Providing reliable power to motors, heaters, and large solenoids in packaging and bottling lines.

Renewable Energy Systems: Used in solar inverter connections and control systems within wind turbines.

Outdoor LED Lighting: A perfect, weatherproof power interface for high-power outdoor LED luminaires, such as street lights and area lighting.

Automated Material Handling: Powering conveyors, sortation systems, and large-scale actuators in logistics centers.

Product FQA

Q1: Can this M12 Connector be used outdoors?
A1: Yes, absolutely. With its IP67 rating, this connector is fully protected against dust and can withstand exposure to rain and temporary water immersion, making it perfectly suitable for outdoor applications like LED street lighting or external control boxes.

Q2: What is the difference between this 220V connector and standard M12 sensor connectors?
A2: The primary difference is the voltage and current rating. Standard M12 sensor connectors are typically designed for 3-5 pins and low-voltage DC signals (e.g., 24V DC). This 220V connector is engineered with specific internal spacing and insulation to safely handle the higher voltages and currents required by more powerful industrial equipment.

Q3: What cable gland does it use, and what cable diameters are compatible?
A3: This unit is typically equipped with a standard PG9 or PG11 cable gland. It is compatible with cable outer diameters ranging from approximately 4mm to 8mm. Please check the product datasheet for the exact specifications for your model.

Q4: Is the LED indicator a standard feature?
A4: The LED indicator is available as an option on many models. Please check the specific product code or contact our sales team to confirm availability for your order.
