Product Description

The Outdoor Waterproof Quick-Connect Terminal is an innovative electrical connection solution specifically engineered for outdoor and harsh environment applications. This 2/3 core connector system features a sophisticated quick-connect mechanism that enables rapid, tool-free installation while maintaining IP68-rated waterproof integrity. The connector employs a advanced bayonet locking system that provides both visual and audible confirmation of proper mating, ensuring reliable connections even in challenging conditions. With its UV-resistant housing and corrosion-proof contacts, this connector series offers exceptional durability for long-term outdoor deployment. The balanced design supports both power and signal transmission, making it versatile for various outdoor electrical applications where reliability and quick installation are paramount.

Product parameters

Product Model :M15

Number of cores :2/3/4/5/2+3 pins

Shell material: Nylon (PA)

Rated voltage :250V

Rated current :10 to 20A

Waterproof rating :IP67/68

Operating temperature :-40℃±105℃

Cable diameter :OD≤ 8.5mm

Connection method: Threaded connection

Product Features
Advanced Quick-Connect Mechanism
Features a patented push-and-rotate locking system that ensures secure connections within seconds. The color-coded alignment markers prevent incorrect mating and provide visual installation guidance.

Superior Waterproof Performance
Triple-sealing design incorporates silicone O-rings, compression seals, and interface seals that work together to provide complete protection against water ingress, even under high-pressure washdown conditions.

UV and Weather Resistance
Specialized housing material formulation provides excellent resistance to UV radiation, ozone, and extreme weather conditions, preventing material degradation and color fading.

Corrosion Protection
Stainless steel locking mechanism and silver-plated contacts ensure excellent corrosion resistance in salty, humid, or chemically aggressive environments.

Polarity Safety Design
Keyed polarization prevents mismating between male and female connectors, protecting equipment from reverse polarity damage.

Strain Relief System
Integrated cable gland with adjustable compression provides excellent strain relief and maintains cable integrity under tension or vibration.

Visual Status Indicators
Clear viewing window allows visual confirmation of proper contact engagement without disconnecting the assembly.

Product Advantages
Installation Efficiency
Reduces installation time by up to 70% compared to traditional Threaded Connectors, significantly lowering labor costs and project timelines.

Maintenance-Free Operation
The sealed design and corrosion-resistant materials eliminate the need for regular maintenance, reducing long-term ownership costs.

Reliability in Extreme Conditions
Maintains consistent electrical performance across extreme temperature ranges and environmental conditions, ensuring system uptime.

Safety Enhancement
The positive locking mechanism and polarization features prevent accidental disconnections and incorrect mating, enhancing overall system safety.

Versatility
Suitable for both power transmission (up to 16A) and signal applications, reducing inventory requirements for multiple connector types.

Cost Effectiveness
The durable construction and long service life provide excellent return on investment, particularly in applications where connector failure would cause significant downtime.

Application Fields
Landscape Lighting Systems

• Garden and pathway lighting

• Architectural accent lighting

• Fountain and water feature illumination

• Outdoor decorative lighting installations

Security and Surveillance

• Outdoor CCTV camera connections

• Security lighting systems

• Access control equipment

• Perimeter security sensors

Recreational Applications

• Swimming pool lighting

• Spa and hot tub connections

• Outdoor entertainment systems

• Garden power tools

Industrial Outdoor Equipment

• Outdoor machinery connections

• Construction site equipment

• Agricultural machinery

• Marine and dock equipment

Renewable Energy Systems

• Solar panel connections

• Wind turbine systems

• Outdoor power storage units

• Remote monitoring equipment

Commercial Applications

• Signage and advertising lighting

• Parking lot illumination

• Building exterior lighting

• Public space lighting systems

Frequently Asked Questions (FAQ)

Q1: What is the difference between IP67 and IP68 rating?
A: IP67 provides protection against temporary immersion (1 meter for 30 minutes), while IP68 offers continuous immersion protection (1.5 meters for 24 hours in our case).

Q2: Can I use this connector for both AC and DC applications?
A: Yes, the connector is suitable for both AC and DC applications up to 250V. However, please ensure proper voltage and current ratings for your specific application.

Q3: How do I ensure proper waterproof sealing?
A: Ensure the O-rings are clean and properly seated, the locking mechanism is fully engaged (audible click), and the cable gland is appropriately tightened for your cable diameter.

Q4: What cable types are compatible?
A: The connector accommodates most round cables from 4mm to 8mm diameter, including rubber, PUR, and PVC cables. For best results, use cables specifically designed for outdoor use.

Q5: Can I mate the connector while it's wet?
A: Yes, the connector is designed to mate and unmate even in wet conditions without compromising the waterproof integrity.

Q6: Is the connector suitable for underground use?
A: While waterproof, we recommend additional mechanical protection for direct burial applications. Please consult our technical team for specific underground installation recommendations.

Q7: How do I determine if I need 2-core or 3-core version?
A: Use 2-core for basic power applications (line and neutral), and 3-core when earth connection is required. For signal applications, choose based on your specific signal requirements.
