Features:

·Screw threaded installation, easy to use and install, stable in utilization.

·Customized for LED street lamp module products, compliant with CSA standards.

·Gold plated electric cores, high corrosion resistance and electrical conductivity, effectively cope with the temperature rise caused by the current.

·The locking ring, rubber core and lagging are all made of high thermoplastic PA material, which is UV resistant and high temperature resistance to 125°C ball pressure test.

·Screw threaded plugging, compression sealing, integrated injection molding, partition and stuck point stop design are adopted to ensure long-term and reliable waterproofing.

·The contact parts are made of solid cores, which meet the requirements of national standard safety regulations.

·Waterproof grade: IP67/IP68.

Product Description
The M15 Universal Matched Waterproof Connector is a specialized electrical connection solution designed specifically for outdoor lighting applications. Engineered by Shenzhen Jiayunkang Technology, a professional manufacturer of waterproof connectors, this product series provides reliable performance in various outdoor environments. With its IP67-rated waterproof protection and durable construction, the M15 connector ensures safe and stable connections for landscape lighting, street lights, garden lights, and other outdoor illumination systems. The connector features a user-friendly push-lock design that enables quick and secure installation while maintaining excellent resistance to water, dust, and UV exposure.

Product Features

• IP67 waterproof rating for complete protection against water and dust ingress

• Universal matching design compatible with various outdoor lighting fixtures

• UV-resistant housing material for long-term outdoor durability

• Push-lock mechanism for quick and secure connections

• High-temperature resistance (-40°C to +105°C) for reliable performance in extreme climates

• Corrosion-resistant contacts with excellent electrical conductivity

• Color-coded connectors for easy polarity identification

• Strain relief design for enhanced cable protection

Parameters:

Product Advantages
The M15 connector offers significant advantages for outdoor lighting applications. Its universal compatibility reduces inventory needs by working with multiple lighting brands and types. The IP67 protection ensures reliable operation in rain, snow, and other wet conditions, significantly reducing maintenance costs and system downtime. The UV-resistant housing prevents material degradation from sun exposure, extending product lifespan. The quick-connect design saves installation time and labor costs while ensuring proper connections every time. Additionally, the temperature resistance allows deployment in various climatic conditions from cold winters to hot summers.

Application Fields

• Landscape lighting systems

• Street light and roadway illumination

• Garden and patio lighting

• Park and public space lighting

• Architectural facade lighting

• Fountain and water feature lighting

• Security and surveillance light systems

• Solar-powered outdoor lighting

Frequently Asked Questions (FAQ)

Q1: What is the IP rating of the M15 connector?
A: The M15 connector has an IP67 rating, meaning it's completely protected against dust and can withstand temporary immersion in water up to 1 meter deep for 30 minutes.

Q2: Is this connector compatible with major outdoor lighting brands?
A: Yes, the M15 features a universal design that works with most outdoor lighting systems, including major brands in the market.

Q3: Can I use this connector for underwater lighting applications?
A: While the IP67 rating provides excellent water resistance, it is not designed for permanent submersion. For underwater applications, please consult us for specialized solutions.

Q4: What wire gauges does the M15 connector support?
A: The connector accommodates wire gauges from 18AWG to 12AWG, making it suitable for most outdoor lighting applications.

Q5: How do I ensure a proper waterproof seal?
A: Ensure the rubber seal is properly positioned and the locking mechanism is fully engaged until you hear a distinct click sound.

Q6: Does the connector require any special tools for installation?
A: No special tools are needed. The connector features a tool-free design for easy installation and maintenance.

Details:
